Certificate Options

Calibration Plan Elements ANSI / NCSL Z540.1 Calibration ANSI / NCSL Z540.1 + Data Calibration ISO/IEC 17025 Compliant ISO/IEC 17025 Accredited ANSI / NCSL Z540.3
Description Satisfies most Quality Management System (QMS) requirements Satisfies most Quality Management System (QMS) requirements with data report Compliant to the standards of ISO/IEC 17025 Meets the standards of ISO/IEC 17025 with accreditation logo Limits probability of false accept (PFA) to no more than 2%
Delivery Method Onsite or lab  Onsite or lab Onsite or lab Onsite or lab Onsite or lab
Calibration Certificate X X X X X
ISO 9000:2015 Compliant X X X X X
Traceable Calibration to National Standards X X X X X
Out of Tolerance (OOT) Notification X X X X X
As Found/As Left Data OOT (2) X X X X
Adjustments and minor repairs (1,3) X X X X X
Measurement uncertainties     X X X
Measurement guard banding (1)     X (4) X (4) X
Accreditation logo on certificate       X X
Notes:
(1)  Services to include adjustments and minor repairs, may vary by instrument type and location
(2)  Data is provided for those parameters found OOT
(3)  All service centers perform adjustments to bring instruments within compliance. Firmware updates and repairs are available for currently supported Tektronix and Keithley Instruments at our factory service centers
(4) Based on decision rule requested by customer

Video Tutorial:
Calibration Service Levels Explained

Calibration Service Levels

Standard Calibration (ANSI/NCSL Z540.1)

This service provides a calibration certificate with a calibration date and calibration due date. A traceability statement is provided. Measurement parameters not meeting the test specifications (out of tolerance) are identified and reported on the certificate.

Standard Calibration with Data (Before/After Data)

This service provides a calibration certificate with a calibration date and calibration due date. A traceability statement is provided. Complete before/after measurement data is provided, listing the test name, measured value and test limits for each parameter tested during the calibration process.
Calibration Service Levels
Calibration Service Levels

17025 Accredited Calibration

Instrumentation is calibrated in accordance with ISO/IEC 17025 within our approved scope of accreditation. Accredited calibrations provide a certificate of calibration with the accrediting body's logo on the document. The calibration date is on the certificate and the calibration due date is only placed on the document when specified by the customer or contractually agreed. A traceability statement is provided. Measurement data and uncertainty for each parameter tested during the calibration is provided.

ANSI/NCSL Z540.3 Calibration

Instrumentation is calibrated in accordance with ANSI/NCSL Z540.3 within our approved ISO/IEC 17025 scope of accreditation. Calibrations provide a certificate of calibration with the accrediting body's logo on the document. The calibration date and the calibration due date (if provided or known) is on the certificate. A traceability statement is provided. Measurement data and uncertainty for each parameter tested during the calibration is provided.
Calibration Service Levels
