Keithley SMU 2650 Series High Power SourceMeter®
The 2650 Series High Power SourceMeter SMU Instruments are designed specifically for characterizing and testing high voltage/current electronics and power semiconductors, such as diodes, FETs, and IGBTs, high brightness LEDs, DC-DC converters, batteries, solar cells, and other high power materials, components, modules, and subassemblies. They deliver unprecedented power, precision, speed, flexibility, and ease of use to improve productivity in R&D, production test, and reliability environments. Two instruments are available offering up to 3000V or up to 2000W of pulse current power.
Base Price
HKD 250,000
+
Keithley SMU 2650 Series High Power SourceMeter®
Features |
Benefits |
| Highly flexible, four-quadrant voltage and current source/load coupled with precision voltage and current meters | Offers best-in-class performance with 6½-digit resolution. |
| Source or sink (2651A) up to 2,000W of pulsed power (±40V, ±50A) or up to 200W of DC power (±10V@±20A, ±20V@±10A, ±40V@±5A); easily connect two units (in series or parallel) to create solutions up to ±100A or ±80V | Supports characterization/testing of power semiconductors, HBLEDs, optical devices, solar cells, and GaN, SiC, and other compound materials and devices. Applications include semiconductor junction temperature characterization; high speed, high precision digitization; electromigration studies; and high current, high power device testing. |
| Source or sink (2657A) up to 180W of DC or pulsed power (±3000V@20mA, ±1500V@120mA) | Provides the high voltage required for power semiconductor device characterization and testing, including GaN, SiC, and other compound materials and devices, breakdown and leakage testing to 3kV, and characterization of sub-millisecond transients. |
| Built-in web browser based software | Allows for remote control through any browser, on any computer, from anywhere in the world. |
| Choice of digitizing or integrating measurement modes | Supports characterizing transient and steady-state behavior precisely, including rapidly changing thermal effects. |
| TSP (Test Script Processing) technology | Avoids communication delays between the PC controller and instrument by embedding test scripts in the instrument itself, improving test throughput dramatically. |
| TSP-Link channel expansion bus | Enables multiple 2651As and 2657As and selected Series 2600B SMU instruments to be combined to form an integrated system with up to 32 channels. |
| Python Drivers Support | Harness the power of native Python commands for controlling instruments and eliminate tedious manual parsing. At your fingertips you’ll find your favorite IDE, such as VS Code or PyCharm. Learn more. |
| Compatible with Model 8010 High Power Device Test Fixture and Model 8020 High Power Interface Panel | Provides safe and easy connections for testing high power devices at either the packaged part or wafer level. |
| Free Test Script Builder software tool | Helps you create, modify, debug, and store TSP test scripts. |
| Optional ACS Basic semiconductor component characterization software | Maximizes productivity when performing packaged part characterization during development, quality verification, or failure analysis. |
Cut Costs and Protect Your Investment
Keithley Care plans provide fast, high-quality services at a fraction of the cost of on-demand service events. You are one click or phone call away from obtaining repair coverage - no quotes, purchase orders, or approval delays.
| Model | Channels | Max Current Source/Measure Range | Max Voltage Source/Measure Range | Measurement Resolution (Current / Voltage) | Power | List Price | Configure And Quote |
|---|---|---|---|---|---|---|---|
| 2651A | 1 | 50A | 40V | 100fA / 100nV | 2000 W | HKD 250,000 | Configure & Quote |
| 2657A | 1 | 120mA | 3000V | 1fA / 100nV | 180 W | HKD 301,000 | Configure & Quote |
| Model | Channels | Max Current Source/Measure Range | Max Voltage Source/Measure Range | Measurement Resolution (Current / Voltage) | Power | List Price | Configure And Quote |
|---|---|---|---|---|---|---|---|
| 2651A | 1 | 50A | 40V | 100fA / 100nV | 2000 W | HKD 250,000 | Configure & Quote |
| 2657A | 1 | 120mA | 3000V | 1fA / 100nV | 180 W | HKD 301,000 | Configure & Quote |
Keithley KickStart Instrument Control Software.
No Programming Required.
Making measurements is easy with KickStart. Characterize your devices and materials quickly and easily without programming. Visualize real-time results in graphical and tabular format. Export data tables or graphs for quick reporting or additional analysis in Excel.
- Create single or sweep pulse tests quickly
- Generate linear, log, list, and dual sweeps of voltage and current source with simultaneous measurement
- I-V characterization application to support up to four SMU instruments
- GPIB, USB, Ethernet connectivity on Windows OS
Automated Control from Lab to Fab
Keithley's Automated Characterization Suite (ACS) offers complete control of your equipment. Whether you need to control a few instruments on your bench, or automate an entire test rack for production, ACS offers a flexible, interactive environment for device characterization, parametric test, reliability test, and simple functional test.
- Perform simple 1-off tests or build complex project trees
- Code with Python inside ACS for unlimited flexibility and control
- Manual or automated wafer prober control
- Data management and statistical analysis capabilities
Accessory
2651A-KIT-3
Datasheet
Description
LOW IMPEDANCE HI CURRENT COAX CABLE KIT ASSY, 3-METERS LG
Accessory
2657A-LIM-3
Datasheet
Description
LOW INTERCONNECT MODULE
Accessory
2657A-PM-200
Datasheet
Description
HI-VOLTAGE 200V PROTECTION MODULE
Accessory
8010
Datasheet
Description
TEST FIXTURE FOR 265xA
Accessory
HV-CA-554-.5
Datasheet
Description
HV TRIAX CABLE, 0.5 M, MALE TO MALE
Accessory
HV-CA-554-1
Datasheet
Description
HV TRIAX CABLE, 1 M, MALE TO MALE
Accessory
HV-CA-554-2
Datasheet
Description
HV TRIAX CABLE, 2 M, MALE TO MALE
Accessory
HV-CA-554-3
Datasheet
Description
HV TRIAX CABLE, 3 M, MALE TO MALE
Accessory
HV-CA-571-3
Datasheet
Description
HV TRIAX FEMALE BKHD UNTERM CABLE, 3 M
Accessory
HV-CS-1613
Datasheet
Description
HV TRIAX FEMALE FEEDTHROUGH CONN
Accessory
SHV-CA-553-1
Datasheet
Description
SHV TO HV TRIAX, 1M, MALE TO MALE
Accessory
SHV-CA-553-2
Datasheet
Description
SHV TO HV TRIAX CABLE, 2 M, MALE TO MALE
Accessory
SHV-CA-553-3
Datasheet
Description
SHV TO HV TRIAX CABLE, 3 M, MALE TO MALE
| Datasheet | Accessory | Description |
|---|---|---|
| View Datasheet | 2651A-KIT-3 | LOW IMPEDANCE HI CURRENT COAX CABLE KIT ASSY, 3-METERS LG |
| View Datasheet | 2657A-LIM-3 | LOW INTERCONNECT MODULE |
| View Datasheet | 2657A-PM-200 | HI-VOLTAGE 200V PROTECTION MODULE |
| View Datasheet | 8010 | TEST FIXTURE FOR 265xA |
| View Datasheet | HV-CA-554-.5 | HV TRIAX CABLE, 0.5 M, MALE TO MALE |
| View Datasheet | HV-CA-554-1 | HV TRIAX CABLE, 1 M, MALE TO MALE |
| View Datasheet | HV-CA-554-2 | HV TRIAX CABLE, 2 M, MALE TO MALE |
| View Datasheet | HV-CA-554-3 | HV TRIAX CABLE, 3 M, MALE TO MALE |
| View Datasheet | HV-CA-571-3 | HV TRIAX FEMALE BKHD UNTERM CABLE, 3 M |
| View Datasheet | HV-CS-1613 | HV TRIAX FEMALE FEEDTHROUGH CONN |
| View Datasheet | SHV-CA-553-1 | SHV TO HV TRIAX, 1M, MALE TO MALE |
| View Datasheet | SHV-CA-553-2 | SHV TO HV TRIAX CABLE, 2 M, MALE TO MALE |
| View Datasheet | SHV-CA-553-3 | SHV TO HV TRIAX CABLE, 3 M, MALE TO MALE |
