2 Series MSO Portable Mixed Signal Oscilloscope
Unlock more space on your bench without compromising performance by choosing our most compact and handheld portable oscilloscope. At only 1.5 inches thick and less than 4 pounds, the 2 Series MSO feels like a tablet while offering the full-featured functionality of a realtime touchscreen oscilloscope. On the benchtop, in the classroom, or to the field, take it wherever your measurement challenges take you.
Up to500MHz
10Mpoints
2or4
Up to2.5GS/s
Portable handheld oscilloscope for daily debug and test
For those seeking the convenience of a portable oscilloscope, the 2 Series MSO delivers unmatched performance. It's small enough to fit into a laptop bag but offers robust specifications, including bandwidths up to 500 MHz and a maximum sample rate of 2.5 GS/s, with options for 2 or 4 analog channels. The front and side I/O ports provide easy access and connectivity. Additionally, the optional detachable battery pack offers versatility for bench or field use.
Simple touchscreen interface and controls
The 2 Series MSO offers the same award-winning touchscreen user interface and simplified control panel you’ve come to expect on the most advanced Tektronix oscilloscopes.
- Simplified front panel with only the most critical controls
- Colored LED ring lights around the knobs indicate active sources or parameters to adjust
- Colored LED light under buttons indicate status
Comprehensive debug with one instrument
With several integrated options, the 2 Series MSO is equipped for all your debugging needs in just one instrument.
- Built-in 16 MSO channels for testing digital circuits (2-MSO instrument option)
- Analyze the frequency response of a system with the built-in Bode plot feature (2-SOURCE software option)
- 50 MHz AFG, 4-bit pattern generator for simulating the circuit under test (2-SOURCE software option)
- Supports a variety of probes to capture a wide range of signals
Comprehensive Analysis for Fast Insight
A full suite of analysis tools provides immediate access to instrument configuration or waveform management tasks with a single tap.
- Waveform and screen-based cursors with user-selectable readout location
- Unlimited automated measurements
- Basic and advanced waveform math including arbitrary equation editing
- FFT for spectrum analysis
Optional accessories add versatility
- Two-slot battery pack supports up to eight hours of battery life and can be hot swapped in the field
- Rack mount kit attaches easily to VESA mount and allows access to all instrument ports
- Optional protective case safeguards instrument from drops up to 40 inches and includes kickstand and carrying bag
- Compatible with many off-the-shelf VESA accessories, including a rolling cart, cup holder mount, desk arm mount, and more
Analyze, share, collaborate with oscilloscope software
Capture data outside the lab, classroom, or any location and collaborate easily with colleagues on the next bench or in the next time-zone.
- Built-in VNC server to control instrument from devices such as PC, tablet, or phone
- TekDrive cloud storage facilitates record-keeping and collaboration
- Analyze data on or off the scope with TekScope™ PC analysis software that works just like the scope
- TekScope and TekDrive offered for six months free
- Kickstart Software enables multi-instrument control, data collection and analysis
- Automate testing with our Python Driver Package
| Model | Analog Bandwidth | Analog Channels | Digital Channels | Sample Rate | Record Length | List Price | Configure And Quote |
|---|---|---|---|---|---|---|---|
| MSO22 | 70 MHz - 500 MHz | 2 | 16 | Up to 2.5 GS/s | 10 M | HKD 15,200 | Configure & Quote |
| MSO24 | 70 MHz - 500 MHz | 4 | 16 | Up to 2.5 GS/s | 10 M | HKD 23,000 | Configure & Quote |
| Model | Analog Bandwidth | Analog Channels | Digital Channels | Sample Rate | Record Length | List Price | Configure And Quote |
|---|---|---|---|---|---|---|---|
| MSO22 | 70 MHz - 500 MHz | 2 | 16 | Up to 2.5 GS/s | 10 M | HKD 15,200 | Configure & Quote |
| MSO24 | 70 MHz - 500 MHz | 4 | 16 | Up to 2.5 GS/s | 10 M | HKD 23,000 | Configure & Quote |
| Tektronix 2 Series MSO |
Keysight 2000 X-Series |
Rohde & Schwarz RTB2000 |
|
|---|---|---|---|
| Channels | 2 or 4 | 2 or 4 | 2 or 4 |
| Bandwidth | 70, 100, 200, 350, 500 MHz | 70, 100, 200 MHz | 70, 100, 200, 300 MHz |
| Sample Rate | 1.25 GS/s (all channels on) 2.5 GS/s (half channels on) |
1 GS/s (all channels on) 2 GS/s (half channels on) |
1.25 GS/s (all channels on) 2.5 GS/s (half channels on) |
| Max Record Length | 10 M points | 1 M points | 10 M points |
| Max Input Voltage | CATII 300 Vrms | 135 Vrms, CAT Rating N/A |
300 Vrms, CAT Rating N/A |
| Trigger Types | Edge, Pulse Width, Runt, Timeout, Logic, Setup & Hold, Rise/Fall Time, Parallel Bus | Edge, Edge then Edge, Pulse, Width, Pattern, Video, Runt, Rise/Fall Time, Nth Edge Burst | Edge, Pulse Width, Video, Pattern, Serial Bus, Timeout, Line |
| Arbitrary Function Generator | 1-channel, 50 MHz | 1-channel, 20 MHz | 1-channel, 25 MHz |
| MSO | 16-channel | 8-channel | 16-channel |
| Protocol Decode | I2C, SPI, RS232/422/485/UART, CAN, CAN-FD, LIN, SENT | I2C, SPI, RS232/422/485/UART, CAN, LIN | I2C, SPI, RS232/422/485/UART, CAN, LIN |
| Display | 10 inch, WXGA, Capacitive Touch | 8.5 inch, WVGA, Non Touch | 10 inch, WXGA, Capacitive Touch |
| Battery | 2 Batteries 8 hours, hot swap | N/A | N/A |
| VESA Mount | 100mm x 100mm | N/A | N/A |
Embedded Design
Embedded designs have never been faster, more complex, and connected so their measurement technology must be on the same wavelength. Engineers need tools that can validate, test and design with speed and accuracy.
- Power supply sequence and measurement
- Serial protocol triggering and analysis for I2C, SPI, RS-232/422/485/UART, CAN, CAN FD, LIN, and SENT
- Device characterization
- Data sharing and remote collaboration
- Control signal capture and analysis with 16 digital channels
Education
Designed with new users and hybrid learning environments in mind, the 2 Series MSO, is the perfect instrument for teaching the next generation of engineers.
- Menus with graphical images and explanatory text for quick feature overviews
- Integrated help system promotes self learning/discovery
- Software enabled for remote teaching, sharing, and learning
- Ability to independently disable autoset, cursors, and measurements.
Automotive
The modern automotive industry moves quickly, and these engineers and technicians need the right oscilloscope at their fingertips to identify issues quickly and easily. The 2 Series MSO combines bench-level performance in a portal scope to help unlock new user experiences and make field debug accessible, precise and repeatable.
- In-vehicle or in-field testing with optional battery pack
- Designing / debugging electronic control units (ECUs)
- Vehicle sensor test and debug
- SENT sensor bus troubleshooting
- Controller Area Network (CAN) bus troubleshooting
- Local Interconnect Network (LIN) bus troubleshooting
Manufacturing
Streamline your manufacturing process by seamlessly transitioning from design to testing on the production floor with the unmatched versatility of the 2 Series MSO oscilloscope.
- Limit and mask testing based on golden reference signal
- Board rework and trouble shooting
- Failure analysis
- Automated test
| Datasheet | Accessory | Description |
|---|---|---|
| 2-BP | Battery Pack with 2 battery slots and 1 battery for use with 2 Series Oscilloscopes | |
| 2-HC | Hard carrying case for 2 Series Oscilloscopes | |
| 2-PC | Protective case for use with 2 Series Oscilloscopes | |
| 2-RK | Rackmount Kit for 2 Series Oscilloscopes | |
| TEKBAT-01 | Additional spare battery for use with battery pack 2-BP | |
| TEKCHG-01 | Battery charger for charging TEKBAT-01 battery |
| Datasheet Link | Probe | Description | Configure and Quote |
|---|---|---|---|
| View Datasheet | A622 | Current Probe: 100 kHz, 10 mA to 100 A, AC/DC, BNC | Configure & Quote |
| View Datasheet | CT1 | CURRENT XMFR; 1GHZ 12A W/PROBE - STATEMENT OF COMPLIANCE | Configure & Quote |
| View Datasheet | CT2 | CURRENT XMFR; 200MHZ 36A W/PROBE - STATEMENT OF COMPLIANCE WITH THIS PRODUCT | Configure & Quote |
| View Datasheet | CT6 | CT6 PROBE; CURRENT PROBE, HIGH FREQ/SMALL GEOMETRY - CERTIFICATE OF TRACEABLE CALIBRATION STANDARD | Configure & Quote |
| View Datasheet | P6021A | Probe, AC Current; 250 Amp AC, 60 MHz, 5 FT w/Term Safety Controlled | Configure & Quote |
| View Datasheet | P6022 | Current Probe: 120 MHz, 1 mA to 3 A, AC, BNC | Configure & Quote |
| TCP2020 | CURRENT PROBE; DC COUPLED, 50 MHZ BW, 20 A, BNC interface | Configure & Quote | |
| View Datasheet | TCP303 | PROBE; AC/DC CURRENT; DC-15MHZ,150A DC, CERTIFICATE OF TRACEABLE CALIBRATION STANDARD | Configure & Quote |
| View Datasheet | TCP305A | Probe, AC/DC Current; 50Amp DC, DC-50MHZ, Certificate of Traceable Calibration Standard | Configure & Quote |
| View Datasheet | TCP312A | Probe, AC/DC Current; 30 Amp DC, DC-100MHZ, Certificate of Traceable Calibration Standard | Configure & Quote |
| View Datasheet | TCP404XL | PROBE; AC/DC CURRENT, DC-2MHZ, 500A DC, 750A DC DERATED WITH DUTY CYCLE,CERTIFICATE OF TRACEABLE CALIBRATION STANDARD | Configure & Quote |
| View Datasheet | TCPA300 | Current Probe: 100 MHz, Amplifier (Requires Probe) | Configure & Quote |
| View Datasheet | TCPA400 | Current Probe: 50 MHz, Amplifier (Requires Probe) | Configure & Quote |
| View Datasheet | TRCP0300 | Current Probe: 30 MHz, 250 mA to 300 A, AC-Only, BNC Interface | Configure & Quote |
| View Datasheet | TRCP0600 | Current Probe: 30 MHz, 500 mA to 600 A, AC-Only, BNC Interface | Configure & Quote |
| View Datasheet | TRCP3000 | Current Probe: 16 MHz, 500 mA to 3000 A, AC-Only, BNC Interface | Configure & Quote |
| Datasheet Link | Probe | Description | Configure and Quote |
|---|---|---|---|
| View Datasheet | P5200A | High Voltage Probe: 50 MHz, 50X/500X, 1.3 kV, Differential, BNC | Configure & Quote |
| Datasheet Link | Probe | Description | Configure and Quote |
|---|---|---|---|
| View Datasheet | P5100A | High Voltage Probe: 500 MHz, 100X, 2.5 kV, Single-ended, BNC | Configure & Quote |
| P5122 | High Voltage Probe: 200 MHz, 100X, 1 kVRMS CAT II, Single-ended, BNC, SAFETY CONTROLLED | Configure & Quote | |
| P5150 | High Voltage PROBE; 50X, 500 MHZ, 2.5 kV | Configure & Quote | |
| P6015A | PROBE HIVOLTAGE; 75MHZ,40KV,1000X 10 FT - CERTIFICATE OF TRACEABLE CALIBRATION STANDARD | Configure & Quote |
| Datasheet Link | Probe | Description | Configure and Quote |
|---|---|---|---|
| P6316 | MSO PROBE; 16 CHANNEL GENERAL PURPOSE PROBE | Configure & Quote |
| Datasheet Link | Probe | Description | Configure and Quote |
|---|---|---|---|
| View Datasheet | P2221 | Passive Probe: 200 MHz, 1X/10X, BNC | Configure & Quote |
| View Datasheet | P3010 | Probe,Passive; 100MHz, 10X, with Readout, for TDS3000 Series | Configure & Quote |
| View Datasheet | P5050B | PASSIVE PROBE; 10X 500 MHZ PASSIVE VOLTAGE PROBE; COVERED BNC | Configure & Quote |
| View Datasheet | P6139B | Passive Probe: 500 MHz, 10X, BNC | Configure & Quote |
| View Datasheet | THP0301-B | 300 MHz 10X passive probe blue | Configure & Quote |
| View Datasheet | TPP0100 | Passive Probe: 100 MHz, 10X, BNC | Configure & Quote |
| View Datasheet | TPP0200 | Passive Probe: 200 MHz, 10X, BNC | Configure & Quote |
| Datasheet | Accessory | Description |
|---|---|---|
| 2-BP | Battery Pack with 2 battery slots and 1 battery for use with 2 Series Oscilloscopes | |
| 2-HC | Hard carrying case for 2 Series Oscilloscopes | |
| 2-PC | Protective case for use with 2 Series Oscilloscopes | |
| 2-RK | Rackmount Kit for 2 Series Oscilloscopes | |
| TEKBAT-01 | Additional spare battery for use with battery pack 2-BP | |
| TEKCHG-01 | Battery charger for charging TEKBAT-01 battery |
Tektronix offers a range of calibration and warranty extension plans for purchase with your instrument to protect and maintain its performance over the years. Benefits include:
- OEM quality maintenance
- Priority on-bench service
- A host of accident protection, loaner program, and other program features
- A breadth of calibration service levels and options
Invest now to avoid unplanned downtime and expense. Talk to your sales rep about adding a service plan to your instrument purchase.
| Service Plan Feature |
Total Protection (Opt. T3, T5) |
Tek Care (Opt. R3, R5) |
|---|---|---|
| Extension of factory warranty |
 |
|
| Protection from manufacturer defects |
|
|
| Free factory certified calibration with repair (if necessary) |
|
|
| Free in-country shipping |
|
|
| Priority on-bench service |
|
|
| Coverage of user-caused EOS and ESD damage |
|
|
| Coverage from accidental damage |
|
|
| Coverage from normal wear and tear |
|
| Calibration Features: |
Z540 Calibration1 |
ISO 17025 Compliant1 |
ISO 17025 Accredited |
|---|---|---|---|
| Certificate of calibration and calibration label designed to meet audit requirements |
|
|
|
| Firmware updates, if applicable, along with safety and reliability updates ² |
|
|
|
| OEM procedures for measurements ² |
|
|
|
| Test data | Optional |
|
|
| Calibration record retention |
|
|
|
| Traceability |
|
|
|
| Uncertainty analysis |
|
|
|
| Independent verification by a ISO/IEC accredited organization (with logo on certificate) |
|
| Product/Option |
Description |
|---|---|
| Tektronix Opt. C3 | Calibration service 3 years. C3 provides for 2 calibration events during 3 years after shipment. Includes traceable calibration or functional verification where applicable, for recommended calibrations. Coverage includes the initial calibration plus 2-years calibration coverage. |
| Tektronix Opt. C5 | Calibration service 5 years. C5 provides for 4 calibration events during 5 years after shipment. Includes traceable calibration or functional verification where applicable, for recommended calibrations. Coverage includes the initial calibration plus 4-years calibration coverage. |
1 May be ISO 9001 in specific locations.
2 Standard with factory certified service.
Some limits apply, see program terms for details.
Need to Calibrate More than Just Your 2 Series?
Tektronix is a leading accredited calibration services provider for all brands of electronic test and measurement equipment, servicing more than 140,000 models from 9,000 manufacturers. With 100+ labs worldwide, Tektronix serves as your single global partner delivering tailored calibration programs with OEM quality at a market price. Onsite, local pickup and delivery, and other options available.
